Flow Meter

Get a Price/Quote

MOQ : 1 Piece

Flow Meter Specification

Humidity %
Up to 95% RH Non-condensing

Connectivity Type
4-20 mA, RS485 Modbus

Frequency
50Hz

Pressure Range
Up to 16 bar

Measurement Range
As per Model, up to 9999 m3/h

Protection
IP65

Current Range
4-20 mA output

Capacity
Depends on Model - up to 10,000 m3/h

Sensor Type
Magnetic Inductive

Temperature Range
0C to 80C

Application Media
Liquid / Water

Diameter
15 mm to 600 mm

Resolution
0.001 m3/h

Flow Rate
0.1 to 10,000 m3/h

Material
Stainless Steel

Power Supply
230V AC, 50Hz

Power Consumption
Less than 15 VA

Accuracy
0.5% of reading

Display Type
Digital LCD Display

Range
0.1 m3/h to 9999 m3/h

Mounting Type
Flange / Wafer

Enclosure Material
Die Cast Aluminium

Compliance
ISO 4064, CE Marked

Power Supply Options
AC / DC selection available

Ingress Protection
IP65 / IP67 / IP68 (depends on model)

Lining Material
PTFE / Hard Rubber / Neoprene

Weight
Varies by diameter and model

Cable Glands
PG11 / PG13.5

Output Signal
4-20 mA, Pulse, RS485 MODBUS

Electrode Material
SS316L

Repeatability
0.1%

Process Connection
Flanged as per ANSI / DIN / JIS

Ambient Temperature
-10C to +55C

Equipment Type
Electromagnetic Flow Meter

Flow Meter Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7 Days

About Flow Meter

Order our resplendent Electromagnetic Flow Meter and discover an instrument engineered for invincible performance and incomparable accuracy. Available for a limited time, this highlighted product boasts SS316L electrodes, PTFE/Hard Rubber/Neoprene linings, and a robust die-cast aluminium enclosure rated up to IP68. Experience digital LCD readouts, multiple mounting selections, and versatile output signals including 4-20 mA and RS485 MODBUS. Precision is ensured with 0.5% accuracy and 0.1% repeatability. Suited for liquids and water, this flow meter meets international standards with ease and reliability.

Key Uses and Features of the Flow Meter

This Electromagnetic Flow Meter is used for accurately measuring flow in liquid and water applications, employing magnetic inductive sensor technology. Its features include exceptional accuracy, digital LCD display, and robust construction with stainless steel material and a PTFE/Hard Rubber/Neoprene lining. Application is straightforward-mount via flange or wafer connection, connect to your preferred signal output (4-20 mA, RS485 MODBUS), and monitor flows ranging from 0.1 m3/h to 10,000 m3/h.

Packaging, Supply, and Export Information

Each flow meter is expertly packed to ensure safe handling. Units are supplied promptly with supply ability matching varied demands. Orders can be handed over at ports or exchanged as per international export protocols. Our main export markets include Asia, the Middle East, and Africa, making us a distinctive manufacturer, supplier, and trader in India delivering premier flow measurement technology worldwide.

FAQ's of Flow Meter:

Q: How does the electromagnetic flow meter ensure accurate readings?

A: The electromagnetic flow meter utilizes magnetic inductive sensor technology, SS316L electrodes, and robust lining materials to achieve 0.5% reading accuracy and a repeatability of 0.1%, ensuring precise measurements even under challenging conditions.

Q: What media can be measured using this flow meter?

A: This flow meter is designed to measure the flow of liquid and water in a wide range of industrial applications, making it suitable for chemical, water treatment, and process industries.

Q: When should different lining materials be selected?

A: The choice between PTFE, Hard Rubber, or Neoprene lining depends on the chemical compatibility with the liquid being measured; PTFE is used for aggressive chemicals, Hard Rubber for standard applications, and Neoprene for specific industrial needs.

Q: Where can the flow meter be installed?

A: The flow meter can be mounted on pipelines using flange or wafer mounting as per ANSI, DIN, or JIS standards, suitable for use in varying ambient temperatures from -10C to +55C and protected up to IP68 depending on the model.

Q: What are the power supply options available?

A: The instrument offers both AC and DC power supply options, enhancing installation flexibility to match the requirements of different operational environments.

Q: How does the output connectivity benefit industrial automation?

A: Multiple output formats including 4-20 mA, pulse, and RS485 MODBUS allow direct integration with SCADA, PLC, and other process control systems, enhancing monitoring and automation potential.
